AET DR-GS-15SF Wood Chipper


Chipper Capacity: 4 – 6 CBM/Hour or 4000L – 6000L/Hour
Wood Diameter: Max. 120mm
*It changes according to the hardness of the material, the degree of bending, the density of the fiber etc.
Blade (Chipper Knife): 2 Sheets
Triangular Blade (Hammer Knife): 10 Sheets
Hydraulic Pump: 10ml/r, 20mpa
Hydraulic Motor: 0-600rpm, Max 240N*M
Hydraulic Oil: 4L
Engine Model: Briggs & Stratton Vanguard V-Twin Engine (USA)
Displacement: 570cc
Max Power: 18HP / 3600rpm
Engine Type: V-Twin, 4 Stroke, OHV, Air-cooled
Bore x Stroke: 72mm x 70mm
Fuel Type: Gasoline
Fuel Tank Capacity: 8.5L
Oil Capacity: 1.7L
Starting System: Recoil Start or Electric Start
Dimension (L x W x H): 3000 x 1200 x 1750mm (including tower hitch)
Net Weight: 280kg
